How Do Substations Work?
An electrical distribution substation is a facility where power from the main transmission grid is transformed for local distribution. The substation may also include equipment to switch circuits or regulate voltage.
Most substations are owned and operated by electric utilities, but some may be owned by large industries or other businesses that require a reliable supply of electricity.
A typical substation includes a transformer to step down the voltage from the transmission system, as well as switches and other devices to control the flow of electricity.
The first distribution substations were built in the late 19th century, as electricity began to be used for lighting and other purposes beyond just powering electric motors. Today, there are thousands of distribution substations around the world, ranging in size from small units serving a few customers to large facilities supplying power to millions of people.
Electrical Substation
An electrical substation is a crucial part of the electric power grid. It is a collection of equipment that steps down high-voltage electricity to a lower voltage so that it can be used by consumers. Substations also help to regulate voltage and manage the flow of electricity on the grid.
A typical substation contains several pieces of equipment, including:
Transformers: These devices change the voltage of electricity passing through them. A substation will have one or more transformers that step down high-voltage electricity from transmission lines to a lower voltage that can be used by distribution lines.
Circuit breakers: These devices protect equipment and prevent outages by automatically disconnecting circuits when there is an overload or fault. Circuit breakers are located throughout a substation, and each one is typically paired with a transformer.
Capacitors and reactors: Capacitors store energy and help regulate voltage, while reactors absorb energy to control current flow.
Both types of equipment are used to improve power quality and prevent damaging surges on the grid.
Busbars: Busbars are made of metal bars that conduct electricity between circuit breakers, transformers, and other equipment in a substation. They are often enclosed in air-filled chambers called bus ducts to reduce the risk of fire or explosion.
Distribution Substation Components
A distribution substation is a power substation that takes electricity from the transmission system and lowers the voltage so it can be sent on to homes and businesses. The components of a distribution substation include:
Transformers: A transformer is used to lower the voltage of electricity so it can be sent on to homes and businesses.
The primary winding of the transformer is connected to the high-voltage side of the circuit, while the secondary winding is connected to the low-voltage side.
Circuit breakers: A circuit breaker is used to protect transformers and other equipment in the substation from damage due to overcurrents or faults in the system. Circuit breakers are also used to isolate equipment for maintenance or repair.
Capacitors: Capacitors are used to improve power factor and reduce losses in the system. They are also used to provide reactive power support for loads.
Reactors: Reactors are used to limit currents in circuits, provide impedance, or store energy temporarily.
They are sometimes used in place of capacitors for power factor correction.
What is Substation
A substation is a part of an electrical generation, transmission, and distribution system. Substations transform voltage from high to low, or the reverse, or perform other important functions. between generating stations and consumers, and between the grid and the local distribution networks.
Types of Distribution Substation
A distribution substation is a utility facility at which electricity is received from a transmission system and transformed to a lower voltage for local distribution. They are often located near the end user, such as an industrial complex or residential neighborhood. A typical distribution substation would receive power from one or more 13,200 volt or higher primary circuits and convert it to one or more secondary circuits of 480 volts or less.
The transformer(s) would be mounted on a concrete pad with energized switchgear arranged around it in a fenced area.
There are three types of distribution substations: air-insulated (AIS), gas-insulated (GIS), and hybrid (HIS).
Air-insulated Substations (AIS): This is the most common type of substation.
In an AIS, the primary equipment is mounted on structures made of insulating materials like porcelain, fiberglass, or composite resin. The secondary equipment is usually mounted either on the same structures as the primary equipment or placed close by on separate structures called bays. Air-insulated substations can range in size from very small installations having only two pieces of equipment to large ones with hundreds of pieces of equipment spread over several acres.
Gas-insulated Substations (GIS): In GIS technology, all primary and secondary components are contained within modular metal enclosures filled with pressurized sulfur hexafluoride gas (SF6). These “all-gas” designs offer several advantages over air-insulated designs including smaller footprint, enhanced reliability, and reduced maintenance requirements. Gas insulated substations cost more to build than air insulated substations but this investment may be offset by their longer service life and lower O&M costs.
require special training for maintenance personnel due to the hazardous nature of SF6 gas..
require hermetically sealed connectors that can withstand repeated cycling without leaks.
.
Hybrid Insulated Substations HIS): HIS combines both GIS and AIS technologies in one installation by placing some components inside SF6-filled modules while others remain outside in the air environment..
This approach provides many benefits including flexibility during design and construction, increased capacity within existing footprints, compatibility with existing systems, ability to use standard techniques for new additions/modifications/upgrades ,and reduced vulnerability to natural disasters..
Types of Substation
A substation is a power plant where electricity is generated and then transmitted to an electricity grid. There are three types of substations: transmission, distribution, and generation.
Transmission substations step up the voltage of the electricity so it can be sent long distances through high-voltage power lines.
These substations are usually located near the power source, such as a hydroelectric dam or thermal power plant.
Distribution substations step down the voltage of the electricity so it can be sent to homes and businesses through lower-voltage power lines. Distribution substations are usually located near population centers.
Generation substations are used for generating electricity from renewable sources such as solar, wind, or geothermal energy. These substations are often located in remote areas where there is little or no access to the electric grid.
Electrical Substation Components Pdf
An electrical substation is a vital component of the electric power infrastructure. It serves as a link between the high-voltage transmission grid and the low-voltage distribution network. The substation transforms voltage from the high-voltage transmission level to the lower voltages used by consumers.
It also provides switching, protection, and control functions.
A typical substation includes a switchyard, transformers, circuit breakers, busbars, and other equipment. The switchyard contains the high-voltage equipment and is surrounded by a fence to protect personnel and equipment from contact with the high voltages.
The transformer steps down the voltage from the transmission grid to a level that can be used by consumers. Circuit breakers interrupt the flow of electricity in case of faults on the system. Busbars are metal bars that conduct electricity within the substation; they are often made of copper or aluminum because these metals have good electrical conductivity.
Other equipment found in many substations includes capacitors, which store energy temporarily; surge arrestors, which protect equipment from sudden spikes in voltage; and ground wires, which provide a path for current to flow in case of a fault on the system.
Distribution Substation Pdf
A distribution substation is a power substation that switches electricity between different voltage levels and sends it on to consumers. The voltages used in distribution are lower than the voltages used in transmission, so the equipment in a distribution substation is less expensive. A typical distribution substation has several transformers, each of which steps down the voltage from the transmission system to a level that can be used by local customers.
The first step in bringing electricity from the power plant to your home or business is through the high-voltage transmission system. This network of wires carries electricity at very high voltages (usually 115,138,161 or 230 kV) over long distances between generating stations and population centers. The second step occurs at a distribution substation where the voltage is transformed (or “stepped down”) from high to medium voltage (usually 13,200 volts).
From there it goes to neighborhood secondary units and finally to customer meters where it is stepped down again for use in homes and businesses (usually 120/240 volts).
Transformers are an essential part of any electric utility grid, whether for transmitting or distributing electricity. In general, their function is to change (or “transform”) electric energy from one form to another.
For example, they can be used to convert high-voltage energy into low-voltage energy suitable for home appliances; or they can be used to convert direct current (DC) into alternating current (AC).
While all transformers perform this basic function, there are important differences among them. The type of transformer most commonly found in electric utility systems is the three-phase autotransformer.
As its name implies, this device uses three separate coils – called phases – wound around a common iron core. Under normal conditions, all three phases carry equal currents and produce equal magnetic fields that cancel each other out.
Credit: electrical-engineering-portal.com
What Does a Distribution Substation Do?
A distribution substation is a facility where voltage from a high-voltage transmission system is transformed to a lower voltage for local distribution. The substation also includes devices such as switches and fuses to protect the distribution system from faults in the transmission system or in customer equipment.
What is the Difference between Distribution And Substation?
In the power industry, a substation is an electrical installation where voltage is transformed from high to low, or the reverse, using transformers. A distribution station performs a similar function but on a smaller scale. The main difference between the two is that a substation serves as a hub for multiple distribution lines while a distribution station only serves one line.
Substations are usually located near power plants or large industrial facilities where electricity demand is high. Distribution stations are typically found along residential and commercial areas served by distribution lines.
What are Types of Distribution Substations?
A distribution substation is a facility where electricity is taken from the high-voltage transmission system and transformed to a lower, usable voltage for local distribution. Substations are also used to switch circuits or lines in or out of service, isolate faults, and protect equipment. A typical substation contains power transformers that reduce the voltage of the incoming line to a level that can be safely used by local customers, as well as circuit breakers and switches that control circuit flow.
There are three types of distribution substations:
1. Step-down Substation: A step-down substation changes high-voltage, long-distance transmissions to medium voltage used for local distribution within cities and towns. Power enters the substation through an overhead transmission line at around 138 kV or 115 kV.
The power is then routed through one or more power transformers that change the voltage to 12 kV, 7200/4160 V, 2400/1320 V, 480 V etc before it exits the substation on underground cables for use by residential and commercial customers
2. Regulating Substation: This type of substation automatically regulates voltage so there are no fluctuations in power supply due to changes in load demand or other factors. 3 Automatic Voltage Regulators (AVRs) installed at a regulating substation constantly monitor voltages and make necessary adjustments using tap changers on the transformer winding(s).
By keeping voltages within specified limits at all times, AVRs improve service reliability while reducing wear and tear on electrical equipment
What are the Three Main Parts of a Substation?
A substation is an electrical installation where equipment is used to switch, transform and distribute electricity. The three main parts of a substation are the primary equipment, the secondary equipment and the control room.
The primary equipment includes power transformers, circuit breakers and disconnectors.
This equipment is used to change the voltage of electricity so that it can be safely distributed to homes and businesses. The secondary equipment includes voltage regulators, capacitors and surge arresters. This equipment helps to stabilize the voltage of electricity so that it does not fluctuate too much.
The control room houses all of the electrical controls for the substation.
Conclusion
A substation is an electrical distribution center where voltage is transformed from high to low, or the reverse. Substations may also be used to switch circuits or regulate voltages. Large industrial complexes will often have their own substations on site to meet their specific needs.
A typical substation includes a transformer, switching equipment, and busbars.
